Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
20
Speed control
scope
1:1000PG card vector control
Speed control
precision
±0.02%PG card vector control 25±10℃)
Torque limit yesset with parameter
Torque
precision
±5%
Frequency
control scope
0120Hz
Frequency
precision
(temperature
fluctuation
±0.1%
Frequency
setting
resolution
±0.06Hz/120Hz
Output
frequency
resolution
calculation of
resolution
0.01Hz
No-load startup
compensation
When the elevator load is unknown, suitable torque will, as per the
ready-to-travel direction of elevator, be applied on motor so as to ensure smooth
start of elevator, minimize the slipping and improve comfort at starting moment
Overload
capacity
Zero speed 150% , < 3Hz is 160%, > 3Hz is 200%
Card
interface
PG card
output
5V12V300mA
PG card type Open collector output, push-pull output, SIN/COSEndat absolute value type
Brake torque 150% ( external braking resistor),integrated braking unit
Acceleration
Deceleration
time
0.01600s
Carrier
frequency
211kHz
Battery
operation
In case of blackout, the battery instantaneously supplies power to elevator for
leveling at low speed
