Instruction Manual for AS380 Series Elevator Integrated Drive Controller
209
F230
Torque
compensation gain
Set torque compensation gain
0.0～
200.0
％
100.0
F231
Torque
compensation bias
Set torque compensation bias
0.0～
100.0
％
0.0
Parameter F164 has the meanings as follows:
F164 set value Model of weighing
device
Acquisition method of light, heavy, full
and over load signal
Acquisition method of compensation
signal
0 DTZZ-III-DC-SC Input open/close signal to the car top
board
Input weighing device signal by CAN,
and then calculate the final
compensation value by weighing device
signal, F193, F194 and F195 parameters
1 DTZZ-II Input weighing device signal by CAN,
and then calculate the result by weighing
device signal
Input weighing device signal by CAN
2 DTZZ-II Input open/close signal to the car top
board
Input weighing device signal by CAN
3 DTZZ-III-DC-SC Input weighing device signal by CAN,
and then calculate the result by weighing
device signal
Input weighing device signal by CAN,
and then calculate the final
compensation value by weighing device
signal, F193, F194 and F195 parameters
4 None Input open/close signal to the car top
board
Calculate the weighing compensation
values at light load and heavy load by
light/heavy switch signal, F193, F194
and F195 parameters, and 40 is set to be
50％ at this time.
5 Input open/close signal to the car top
board
Input weighing device signal by analog
signal
6 Input weighing device signal by analog
signal, and then calculate the result by
weighing device signal
Input weighing device signal by analog
signal
99 Input open/close signal to the car top
board
None
Different types of weighing devices correspond to three different adjustment methods: the
first is use of DTZZ-III-DC-SC weighing device (F164 set to 0 or 3); the second is Use of
non-DTZZ-III-DC-SC weighing device (F164 set to 1, 2, 5 or 6); the third is without weighing
device, a simple compensation by using light-load and heavy-load switch. The following three
sections make a detailed introduction on how to adjust the three parameters F193 ~ F195 or 229 ~
F231 in the three start compensating methods. In the absence of start compensation, the four
parameters F164, F193 ~ F195 do not need to be set, and their default value 0 will be ok; the three
parameters 229 ~ F231 can also use their default values.
