Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
219
leveling floor Failure 28 reported, when the action on the sensor for lower leveling floor is
greater than the maximum effective protection distance or greater than the
maximum invalid protection distance
When the length of the leveling spile is less than 300mm: maximum
protection distance for effective action = 300mm*4
When the length of the leveling spile is greater than 300mm: maximum
protection distance for effective action = length of the leveling spile*4
When the top floor is less than 3: maximum protection for invalid action
= maximum story height*1.5
When the top floor is greater than 3: maximum protection for invalid action
= maximum story height*2.5
30
Leveling position error is too
large
Test the leveling position error at stop. Failure report when the error detected
is greater than the value set by F146.
32
Safety loop disconnected in
operation
Safety loop disconnected in operation
35
Brake contactor contact fault
Motherboard has no drive signal on brake contactor, but input signal is
detected at input testing point (adhesion failure)
Motherboard has drive signal on brake contactor, but input signal is not
detected at input testing point (non-adhesion failure)
36
Output contactor contact fault
Motherboard has no drive signal on circuit contactor, but input signal is
detected at input testing point (adhesion failure)
Motherboard has drive signal on circuit contactor, but input signal is not
detected at input testing point (non-adhesion failure)
37
Door-lock failure
Door- lock close signal input when the door-open limit signal is in action
When door-lock relay detection is set, the lock input point has
inconsistent high and low voltage detection
38
Brake switch malfunction
Motherboard has no drive signal on brake contactor, but open/close action is
detected at brake switch input testing point (adhesion failure)
Motherboard has drive signal on brake contactor, but no open/close action is
detected at brake switch input testing point
40
Run signal failure
The control part of the AIO sends out run signal, but does not receive the run
signal feedback from the drive part
42
Deceleration switching error
Overtravel in upward movement and the lower level forces slow open/close,
or overtravel in downward movement and the upper level forces slow
open/close
45
Pre-opening relay detection
fault
when the pre-opening relay output is detected inconsistent with the
pre-opening for over 0.5s, Y14 has output, but X17 has no input; Y14 has no
output but X17has input
