Instruction Manual for AS380 Series Elevator Integrated Drive Controller
230
reservoir
electrolytic
capacitor
1) check for liquid leakage, fade,
fissure, expansion of casing
2) if safety valve works normally and if
expansion occurs to valve body
Visual inspection No abnormality
Heat sink
1) Check for dust
2) Check for blocking or foreign
materials in air tunnel
Visual inspection No abnormality
Cooling fan
1) Check for abnormal noise,
2) Check for abnormal vibration;
3) Check for fade and deformation due
to overheat
1) Acoustic/visual
inspection. Turn the
fan blade after
powering off
2) Visual
inspection
3) Visual
inspection, olfactory
inspection
1) Rotate smoothly
2),3)no abnormality
Control circuit
Wiring Plugs
Check for dust and absorbed foreign
materials on double-bank plug-in
assembly between control board and main
circuit
Visual inspection No abnormality
Control panel
1) Check for fade and off odor of control
circuit board
2) Check for fissure, breakage and
deformation of circuit board
1) Visual/
olfactory inspection
2) Visual
inspection
No abnormality
