STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
264
Code
Fault
Description
Possible Cause Solution
in converter output side
connection
Output terminal is loose
Electrical power is too
small, 1 / 20 or less of the
maximum applicable
motor capacity in
the converter
Adjust converter capacity or motor capacity
Unbalanced
output three-phase
Check whether the motor wiring is intact
Power off, check whether the converter output side is
consistent with the features of DC side terminal
81
Motor
overcurrent at
low speed (in
acceleration)
Low voltage in power grid Check the input power
Abnormal motor parameters Set correct motor parameters
Quick start the motor in
operation
Restart after the motor stops rotating
Motor
overcurrent at
low speed (in
deceleration)
Low voltage in power grid Check the input power
Excessive load inertia Use appropriate braking components
Abnormal motor parameters Set correct motor parameters
Deceleration time is too
short
Extend the deceleration time
Motor
overcurrent at
low speed (in
constant speed)
Load mutation in operation
Reduce the mutation frequency and magnitude of the load
Abnormal motor parameters Set correct motor parameters
82
Encoder fault
Encoder not connected
correctly
Change Encoder wiring
Encoder has no signal output Check the Encoder and power supply
Encoder wiring disconnected Repair the disconnection
Abnormal function code
setup
Confirm the relevant functional configuration of the
converter Encoder
83
Current
detected at stop
Current not effectively
blocked when the motor
stops
Synchronous motor skid
Ask professional technical personnel for Inspection
84
Velocity
Reverse speed in operation Check the external load for mutation
