Instruction Manual for AS380 Series Elevator Integrated Drive Controller
71
L22 GROUP Parallel
connected/grou
p control
communication
flash-in communication
L23 INS/NOR inspection/auto
mode
Light on mean auto/light off mean inspection
L24 ENCODE rotating encoder Light on –speed feed back
L25 SAFETY Safety circuit Light on-safety circuit turn on
L26 DL Master door
lock
Light on- master door lock circuit turn on
L27 HDL Hall door lock light on- hall door lock circuit turn on
5.1.2 Function key
9 button at the under part of operator, the key function see table 5.1
Table 5.1 button function description
button
Button
name
function
Up button
1.move up by one item when browsing menu
2. the current number increase by 1 when input data
Down
button
1. move down by one item when browsing menu
2. the current number decrease by 1 when input data
Left button
1.move left one menu when select function
2. move left cursor when input data
Right
button
1.move right one menu when select function
2.move right cursor when input data
ESC
Esc button
1.cancel input when input data
ENTER
Enter button
1.change parameter when browsing parameter
2. save when input data
MENU
button
1.enter the LED indicator light function select interface
2.enter the open/close door control interface
F1
F1 button
Press the button at open/close control interface to open the
door
F2
F2 button
Press the button at open/close control interface to close the
door
MENU
