Steris Basil 4700 - Page 161

7-6
764333-098
Figure 7-6. Carriage Drive System
Brass Cap
Inner Roller Bracket
Carriage
Eye Bolts
Drive Cable
Inner Roller
Bracket
Brass Cap
Outer Roller Bracket
Limit Switch (Rabbit Ears)
Limit Switch Actuator
Block
Limit Switch (Rabbit Ears)
Drive Motor
with Capstan
Drive Cable
Outer Roller Bracket
Figure 7-7. Wrap Cable Around Capstan
Capstan
Cable (Left Half)
Three Revolutions
Around Capstan
Cable (Right Half)
