6 Maintenance
Preparatory tasks for maintenance
1044_001-003
1
3
2
Removing the bonnet
The bonnet must be removed before servicing.
Proceed as follows:
– Remove 2 screws (1) and (2).
– Remove the bonnet (3).
CAUTION
Do not damage electric cables.
1044_001-004
1
2
3
Installing the bonnet
– Install the bonnet (3) from above with the
guiding lugs (1) in the openings (2) in the
frame.
– Fasten the bonnet w
ith 2 screws from
above.
