Objet260 User Guide 6 Operating and Maintaining the Objet260 3DPrinter
DOC-37004 Rev.E 6-62
TotestandcalibrateUVlampradiation:
1. StarttheUVCalibrationWizardfromtheOptionsmenu.
2. Inthefollowingscreen,selectCalibrateUVIntensitytoadjustthelamp’s
radiationleveltotheacceptablerange.
Figure6-89UVTest/Calibrationselection
3. Inthefollowingscreen,selecttheUVsensorandmeasuringdevicetobe
used.
Figure6-90UVdeviceselection
UV Measuring Device
WhenyouusetheStratasysUVsensorbox(TOL-03005-S),youconnect
ittotheprinter.ThewizardautomaticallymeasuresandcalibratestheUV
radiation.
Ifyouuseastand-aloneUVradiationmeter,youneedtomanuallyenter
thereadingsfromthemeterinthewizardscreens.
