Objet260 User Guide 5 Using Objet Studio
DOC-37004 Rev.E 5-39
Setting Model
Dimensions
Youcanchangeanobject’sdimensionsbychangingitssizeontheX-,Y-,and
Z-axes,fromtheDimensionsgroupontheModel Settingsribbon.
Figure5-44DimensionsontheModel Settingsribbon
•IfUniform Scaleisenabled,changingtheobject’sdimensionononeaxis
affectstheotherdimensions,proportionately.
•Afterchangingameasurement,pressEnterorclickinanotherfieldinthe
Dimensionsgroup.
Note: Youcanchangetheheightoftheobjectsonthebuildtrayonlyifthisis
allowedbytheObjetStudiosettings(see"PositioningObjectsontheZ-Axis"on
page5-35).
Therecommendedminimumsizeforeachobjectonthebuildtrayis
800mm(ontheX-axis)and130mm(ontheY-axis).Althoughsmaller
objectscanbeprinted,theseminimumdimensionsensuregoodprint
quality.
Repositioning
Objects
Youcanmanuallymoveandrotateanobjectonthebuildtraywiththearrow
keys,orbydraggingitwiththemouse.
Tomanuallymanipulateanobject:
1. Selectanobjectbyclickingitonthebuildtray,orinthemodeltreepane.
2. Click ontheModelToolbar,orontheModel Settings ribbon.
Aframeappearsaroundtheobject,andthecursorchangestoindicate
thattheobjectcanbemoved.
Figure5-45Manuallymovinganobject
