Removing and Inserting an Internal Hard Disk Drive
5-44 Stratus ftServer 2600, 4500, and 6300 Systems: Operation and Maintenance Guide (R639)
5. Replace the enclosure cover.
6. Replace the CPU-I/O enclosure.
7. Replace the bezel.
Removing and Inserting an Internal Hard Disk Drive
You can remove hard disk drives from a CPU- I ⁄ O enclosure to replace them or to
perform other maintenance procedures. You do not need to power down the system or
either CPU-I/O enclosure to perform this procedure. See the following topics:
• “Removing an Internal Hard Disk Drive” on page 5-44
• “Replacing an Internal Hard Disk Drive” on page 5-45
Estimated time: Less than a minute for each disk drive.
Tools: None.
Use ESD precautions when performing this procedure.
NOTE
Anytime you remove more than one disk drive at a time,
label the drives on the bezel of each drive to ensure that
you can replace them in the proper order. The numerical
slot designation for each disk is noted on the front of the
drive bay.
Removing an Internal Hard Disk Drive
1. Remove the bezel.
2. Press the green release button (number 1 in Figure 5-25) on the latch on the front
of the disk drive, pull the latch (number 2), and remove the disk drive.
CAUTION
!
If the status LED for a disk drive is blinking yellow, do not
remove the drive (see Tab le 3-4).
CAUTION
!
Do not pull the drive; use the latch.
