Status LEDs and System Buttons
3-12
Stratus ftServer 2600, 4500, and 6300 Systems: Operation and Maintenance Guide
(R639)
Ethernet and VTM Port LEDs
Each CPU- I ⁄ O enclosure contains:
• Two Ethernet ports that operate at 10, 100, or 1000 Mbps and connect to the
embedded Ethernet controller. Each port has two integrated LEDs that indicate
Ethernet activity and connection speed.
• One VTM port that has two integrated LEDs that indicate activity and connection
speed.
Figure 3-4 shows the LEDs for the Ethernet ports and VTM ports.
Blinking yellow Unsafe to remove: The disk drive is simplexed.
• If the drive is part of a mirrored drive pair, the partner drive
is unavailable.
Action: Reinsert the partner drive to restore duplex
operation. Verify that the partner drive is functioning
normally.
• If the drive is not part of an mirrored pair, a non-mirrored
volume exists on the drive. Or, a mirrored volume exists on
the drive, but its partner volume is unavailable.
Action: If the drive contains a mirrored volume, reinsert the
drive that contains its partner volume to restore duplex
operation. If the drive is not mirrored, consider creating a
mirrored drive pair or another type of mirrored set to
increase fault tolerance.
• If the drive is part of a mirrored drive pair or it contains part
of a mirrored volume pair, the drive or volume is
resynchronizing.
Action: Wait for the process to complete.
See your system administration documentation for information
about mirrored volumes.
Rapid, intermittently
blinking green
Disk is duplexed (all volumes are mirrored), data is being
written to or read from the disk, and the disk is safe to remove.
Table 3-4. Hard Disk Drive LEDs
(Continued)
Status Description
