Removing and Replacing a Front Panel
5-6 Stratus ftServer 2600, 4500, and 6300 Systems: Operation and Maintenance Guide (R639)
Removing and Replacing a Front Panel
Remove the front panel to replace it. Also, release it—but do not remove it—to replace
the DVD drive. You do not need to power down the system or either CPU-I/O enclosure
to remove and replace a front panel assembly. See the following topics:
• “Removing the Front Panel” on page 5-6
• “Replacing the Front Panel” on page 5-8
Estimated time: Two minutes.
Tools: None.
Use ESD precautions when performing this procedure.
Removing the Front Panel
You do not need to turn the system off when removing or replacing a front panel.
The replacement front panel does not include a DVD drive. You must remove the DVD
drive from the defective front panel and install it in the replacement front panel.
CAUTION
!
The DVD drive is not hot-pluggable: Remove and replace
the DVD drive only while the front panel is disconnected
from the system backplane.
1. Remove the bezel.
2. Loosen the captive thumbscrew (number 2 in Figure 5-2) at the bottom of the front
panel (number 1).
