79
External Amp Output Power Supply
DVI-D Input* RS232 Port
DVI-I Input
Control System Port
Optical DVI-D Input USB Port
Video Processing Module KVM Port
* If the SDC or All-In-One Control System controls the router, this will be a DVI-I input.
** This output will be a VPM card for All-In-One Control Systems.
†
Connects to a potential equalization conductor. The resulting medical electrical system
shall follow all applicable IEC 60601-1 requirements.
Fan Module
Input Slots
1-8
Audio
Module
Output Slots
1-8
Video Pass-
Through Module
Control/KVM
Module
Expansion
Module
Power
Button
FFiigguurree 5544.. SSPPII33--LLiittee RRoouutteerr
DVI-D Input*
Video Processing Module
DVI-D Input
Optical DVI-D Output
DVI-I Input
Equipotential Ground Plug
†
SDI-Video Input Control System Port
Optical DVI-D Input
Keyboard
