82
TToouucchh PPaanneell
Characters on the screen
are dim
Refer to the ON-Screen Display (OSD) Touch Panel
section to adjust the brightness
The Touch Panel screen is
blank
(see the warning at the end
of the Video section of this
trouble shooting guide)
• Make sure the Touch Panel is ON
• Make sure the SPI3 router is ON
• In the event that the Touch Panel is operating in KVM
mode, the monitor screen may automatically turn off
as a result of a remote computer’s Power Saving
feature. Press the close button in the upper right
corner of the Touch Panel, or press any key on the
keyboard to see if the display reappears. Refer to the
ON-Screen Display (OSD) Touch Panel section to
adjust the brightness
• Make sure the power and video cables are firmly
connected to the Touch Panel
Screen flashes when the
Touch Panel is first turned
on
Unplug the power cable of the Touch Panel and then plug
it in again
Touch doesn’t work
• Ensure the serial or USB cable is securely attached
to both Control Section and Touch Panel
• Calibrate the Touch Panel by pressing CTRL+ALT+C
and follow the on-screen instructions
Touch doesn’t work when
trying to control the SDC
The SDC may not be properly calibrated; Contact Stryker
Technical Support
Picture color is unusual or
rolling on the Touch Panel
display
Check the tightness of the “in and out” connections of the
video cables on the back of the Touch Panel and at
Output1 on the Video Router
Cannot calibrate Touch
Panel
Ensure the serial or USB cable is securely attached to the
Touch Panel and Control System
System is slow to respond Reboot the system. If rebooting does not solve the
problem, contact Stryker Technical Support.
Color bars on Touch Panel • Ensure Control System is on
• Ensure the power and video cables are firmly
connected to the back of the Control System
PPoowweerr
Symptom Action
Router will not power up
• Check to see if power cable is firmly connected
• Ensure front power switch is ON
To Next Page
