SummaCut User’s Manual
General Information 1-4
1.2 SPECIFICATIONS
1.2.1 CUTTER
D60(SE) D120(SE) D140SE D160SE
mm inch mm inch mm inch mm inch
Height 300 11.8 1120 44.1 1145 45.1 1145 45.1
Width 1000 39.4 1600 63.0 1750 68.9 1980 79.9
Depth 350 13.8 680 26.8 680 26.8 680 26.8
Weight 15 kg 33 lbs 42 kg 92 lbs 48 kg 106 lbs 54 kg 119 lbs
TABLE 1-1 :
SUMMACUT SPECIFICATIONS
1.2.2 MEDIA
D60(SE) D120(SE) D140SE D160SE
mm inch mm inch mm inch mm inch
Width
Roll
70 to
670
2.8 to
26.4
120 to
1270
4.7 to
50.0
180 to
1430
7.1 to
56.3
180 to
1620
7.1 to
63.8
Sheet
70 to
775
2.8 to
30.5
120 to
1375
4.7 to
54.1
180 to
1525
7.1 to
60.0
180 to
1620
7.1 to
63.8
Pinchrollers
2 3 4 4
Max.Cutting/
Plotting area
600 mm
x 50m.
23.6’’x
164 ft.
1200 mm
x 50 m
47.2’’ x
164 ft.
1350 mm
x 50 m
53.1’’ x
164 ft.
1575 mm
x 50m
62’’ x
164 ft.
mm inch
Minimum
Margins**
25 1
Front margin
18 0.7
Rear margin
Sensor on 42 1.7
Sensor off 25 1
Tracking
performance
8 m/26 feet max. within
guaranteed
specifications*
-8 m/26 feet max. within guaranteed specifications* for media
less than 762 mm (30’’ wide).
-4m/13 feet max. within guaranteed specifications* for media
larger than 762 mm (30’’).
Thickness
0.05 to 0.25 / 0.8mm with optional sandblast knife
0.002 to 0.01 / 0.03 inch with optional sandblast knife
* Media lengths larger than 8 m (26 feet) can be handled, but compliance with specifications is not
guaranteed (will be dependent on media type, media size and other parameters not mentioned here.
** For positioning of the pinch rollers (see section 1.7)
TABLE 1-2:
SUMMACUT MEDIA SPECIFICATIONS
