SummaCut User’ s Manual
Operation 2-17
2.3.20 MEDIA SENSOR
The MEDIA SENSOR submenu is used to activate or deactivate the media sensor. The
sensor detects the end of media. In that way the sensor prevents damage to the cutting
strip and knife tip.
After pressing the
key, press the or jogging key until the desired setting
is displayed on the LCD and press
to confirm.
On the LCD, the active setting is marked with an “*”.
2.3.21 SENSOR SETUP
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
The SENSOR SETUP submenu is used to activate or deactivate the media. After
pressing the
key, follow the instructions on the LCD. Put a piece of media half on
the sensor and then press the
key. The machine will show on the LCD whether
the sensor works or not.
2.3.22 CALIBRATE X/Y
Calibration allows changing the length of the lines that are cut to be adjusted to within
the specifications.
For instance, if a cut line should measure 100 mm exactly, the cutter can be adjusted
for any discrepancy.
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
First make sure the media is loaded, and then press the
key to perform a test.
Measure the lines and enter the measured x-value by pressing the jogging keys.
The
or jogging key change the values in big steps, the or jogging
key change the value in small steps. After pressing the
key, the y-value can be
changed in the same way.
Do not perform this test when the machine is working properly.
