SummaCut User’s Manual
General Information 1-6
1.2.4 INTERFACE
Communication
Standard asynchronous RS-232-C and
Universal Serial Bus.
Serial : I/O Port connector
DB-9P
Mating connector
DB-9S
Byte format
8 data bits, 2 stop bits, no parity
Baud rate
38400, 19200, 9600, 4800, 2400 bps
USB : I/O Port connector
USB series “B” receptacle
Mating connector
USB series “B” plug
Buffer Size
16MB
TABLE 1-4:
SUMMACUT INTERFACE SPECIFICATIONS
1.2.5 FIRMWARE
Language
DM/PL, HP-GL (758x emulation), HP-GL/2
Supported character sets
Standard ASCII
Supported fonts
Sans serif (single stroke & medium)
ROM-based plots
Confidence plot, DIN plot
TABLE 1-5:
SUMMACUT FIRMWARE
1.2.6 PERFORMANCE
Cutting specifications on 0.05 mm (0.002") wax-backed vinyl, total media thickness not
greater than 0.25 mm (0.010")
Axial speed
50 to 800 mm/s 2 to 32 ips
Maximum Speed
Up to 1131 mm/s diagonal Up to 44 ips diagonal
Default speed
700 mm/s 28 ips
Axial Acceleration
up to 2 G
Max. Acceleration
up to 3 G diagonal
Addressable resolution
0.025 mm, 0.1 mm 0.001", 0.005"
Default resolution
0.025 mm 0.001"
Mechanical resolution
0.0127 mm 0.0005"
Repeatability*
+/- 0.1mm +/- 0.004”
Accuracy*
0.2% of move or 0.25 mm,
whichever is greater
**
0.2% of move or 0.010",
whichever is greater
**
Knife pressure
0 to 400 gr.
Pen pressure
0 to 400 gr.
Pouncing pressure
0 to 250 gr.
*
Valid within the guaranteed tracking length (see table 3)
**
Excludes differences due to media expansion, stretching, etc.
TABLE 1- 6:
SUMMACUT PERFORMANCES
