SummaCut User’ s Manual
Operation 2-10
2.3.1 CONFIDENCE
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
The CONFIDENCE cut performs an electrical and mechanical test of the cutter to make
sure that the cutter is fully operational. A media sheet of at least A3/A- size should be
used for this plot.
Press the
key to execute.
2.3.2 DIN CUT
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
The DIN CUT also performs an electrical and mechanical test of the cutter, in order to
check the cut quality, but also provides the user with feedback on knife setting, knife
pressure, knife offset and cutting depth.
This cut is always run as a DIN A4 portrait/A-size image, regardless of the actual size
of the media loaded. If the media loaded is smaller than DIN A4/A-size, part of the
outer box will be clipped (not cut). This cut is always executed in the sequence
prescribed by the ISO DIN standard.
Press the
key to execute.
2.3.3 TOOL
The TOOL submenu is used to select the default tool at power up.
After pressing the
key, press the or jogging key until the desired tool is
displayed on the LCD and press
to confirm.
To configure the cutter for plotting operations, select PEN.
To configure the cutter for cutting operations, select the DRAG KNIFE option.
To configure the cutter for pouncing operations, select the POUNCING TOOL option.
On the LCD, the active tool setting is marked with an “*”.
