1.8.2 PEN INSTALLATION
The SummaCut can also be operated with a pen. After replacing the knife with a pen,
the cutter can be used as a plotter to draw draft plots of new or existing designs on
paper.
 To install the pen, proceed as follows:
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
• Power up the cutter and load a piece of media in the cutter (See 1.7.).
• Press the
key until “SYSTEM TEST” is displayed on the LCD.
• Press the
key.
• Press the
key until “TOOL” is displayed on the LCD.
• Press the
key. The current tool is now displayed.
• Press the
or key until “PEN” is displayed on the LCD.
• Press the
key to confirm tool change.
• Press the
key twice to come in normal mode.
• The cutter will now ask to insert the pen, if that was not the former tool.
Press any key to confirm
• Analogous to 1.8.1., point 6, the pen pressure can be changed.
