SummaCut User’ s Manual
Operation 2-5
2.2.4 KNIFE PRESSURE
The KNIFE PRESSURE parameter is used to set or modify the cutting pressure of the
knife.
The default knife pressure value is 120 grams.
After pressing the
key, press the or jogging key until the desired
pressure is displayed on the LCD and press
to confirm.
The knife pressure can be set between 0 and 400 grams.
The knife pressure value is set in 5 gram increments.
Knife pressure set-up is explained in detail in section 1.8.1.
On the LCD, the active knife pressure is marked with an “*”.
2.2.5 KNIFE OFFSET
The KNIFE OFFSET parameter is used to set or modify the distance between the knife
blade tip and the centre axis.
The default knife offset value is .45 mm.
After pressing the
key, press the or jogging key until the desired knife
offset is displayed on the LCD and press
to confirm.
The value can be set between 0 and 1 mm.
Make sure that the selected knife offset value matches that of the knife. Some fine-
tuning may be necessary because of the mechanical tolerances on the knife.
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
To verify the knife offset, a test can be cut by pressing on the
key.
If the offset value is set too low, the rectangles will not close.
When the offset value is set too high, the rectangles will be distorted.
The offset test is illustrated below.
