SummaCut User’ s Manual
Contour Cutting 3-10
3.7 REGISTRATING THE CROSS-MARKS
• Before proceeding, make sure all the cutting parameters are correct (pressure,
velocity, …). See section 2.
• Press the
key until “ALIGN LOAD” comes on the LCD.
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
• Press the
key.
• Position the knife tip exactly above the origin-marker using the
, , or
jogging keys.
• When above the origin-marker press the
key
During this entire procedure, make sure that the knife does not rotate, which may
cause an offset error.
Indicate the cross-marks with extreme accuracy because it directly influences the
result.
• Position the knife tip exactly above the next marker using , , or
jogging keys.
• When above the origin-marker press the
key
