SummaCut User’ s Manual
Operation 2-14
2.3.10 BAUD RATE
The BAUD RATE submenu is used to set or modify the operating baud rate for RS-
232-C serial communications between your cutter and the host computer.
The default baud rate is 9600 bps.
After pressing the
key, press the or jogging key until the desired baud
rate is displayed on the LCD and press
to confirm.
The baud rate can be set to any of the following values: 2400 bps, 4800 bps, 9600 bps,
19200 and 38400 bps.
On the LCD, the active baud rate value is marked with an “*”.
NOTE
The baud rate setting of your cutter MUST match the host computer's baud rate
setting.
2.3.11 PARITY
The PARITY submenu is used to set or modify the byte format and parity type for RS-
232-C serial communications between your cutter and the host computer.
The default parity setting is bit 8 = 0 (8 data bits, no parity, the 8th bit being a low bit).
The parity can be set to any of the following values:
LCD information Parity setting Remarks
BIT 8 = 0
8 data bits, no parity bit 8 = low (0)
BIT 8 = 1
8 data bits, no parity bit 8 = high (1)
EVEN
7 data bits, 1 parity bit parity bit = even
ODD
7 data bits, 1 parity bit parity bit = odd
After pressing the
key, press the or jogging key until the desired setting
is displayed on the LCD and press
to confirm.
RTS/DTR can be set to TOGGLE (hardware handshaking) or HIGH (software
handshaking).
On the LCD, the active parity setting is marked with an “*”.
NOTE
The parity setting of your cutter MUST match the host computer’s parity setting.
