Chapter 7 Checking LEDs 7-5
7.3.1 I/O Controller Module LEDs
FIGURE 7-3 shows the Sun StorEdge 3510 FC Array I/O controller module and the
LEDs on its back panel.
FIGURE 7-4 shows the Sun StorEdge 3511 FC Array I/O
controller module and the LEDs on its back panel.
FIGURE 7-3 Sun StorEdge 3510 FC Array I/O Controller Module and Battery Module
LEDs
FIGURE 7-4 Sun StorEdge 3511 FC Array I/O Controller Module and Battery Module
LEDs
Ethernet active
Ethernet link
Battery
SFP link status
SFP speed
RAID controller status
I/O activity Cache
H/D/RCC
Ethernet active
Ethernet link
BatteryI/O Activity
Cache
RAID Controller Status
SFP link status
SFP Speed
