B-10 Sun StorEdge 3000 Family Installation, Operation, and Service Manual • May 2004
Caution – Be careful not to mount the same drive twice if you are not using
multipathing software.
B.7.3 Changing Your SFP Configuration on JBOD
Arrays
Sun StorEdge 3510 FC JBOD arrays use SFP connectors to attach to Fibre Channel
ports on your host computer. You might need to move or add one or more SFP
connectors to your Sun StorEdge 3510 FC JBOD array to connect it to your host
computer.
■ To make connections to an empty port, first slide the SFP connector into the port
so that it connects firmly with the chassis. Then plug the fiber-optic cable’s SFP
connector into the duplex jack at the end of the SFP.
■ To remove an SFP connector, make sure no cable is connected to it and then slide
it out from the port.
For more information about SFPs, refer to the Sun StorEdge 3000 Family Installation,
Operation, and Service Manual for your array.
TABLE B-4 Example of 24 Drives Shown on a 12-Disk Sun StorEdge 3510 FC JBOD Array
Connected to a Host Over Two FC Loops
Drive Identifier
(First Loop)
Drive Identifier
(Second Loop)
c1t0d0 c2t0d0
c1t1d0 c2t1d0
c1t2d0 c2t2d0
c1t3d0 c2t3d0
c1t4d0 c2t40d0
c1t5d0 c2t5d0
c1t6d0 c2t6d0
c1t7d0 c2t7d0
c1t8d0 c2t8d0
c1t9d0 c2t9d0
c1t10d0 c2t10d0
c1t11d0 c2t11d0
