Chapter 1 Product and Architecture Overview 1-3
1.1.1 Sun StorEdge 3510 and 3511 FC Array
Configurations
Sun StorEdge 3510 and 3511 FC arrays can be used in the following configurations:
■ Single controller configuration. A RAID array can be configured with a single
controller in a non-redundant configuration.
■ A RAID array with two controllers. A RAID array can be configured with two
controllers to provide full redundancy.
■ An expansion unit. An expansion unit consists of a chassis with disk drives and
I/O expansion modules. The expansion unit does not include an I/O controller
module. The expansion unit connects to and is managed by a RAID array
■ A Just a Bunch of Disks (JBOD) array. The JBOD array connects to, and is
managed by, a host server. Only the Sun StorEdge 3510 FC JBOD is supported.
See “Using a Standalone JBOD Array (Sun StorEdge 3510 FC Array Only)” on
page B-1 for detailed information about using Sun StorEdge 3510 FC JBOD arrays.
TABLE 1-2 shows the configuration options for Sun StorEdge 3510 and 3511 FC arrays.
Maximum FC Host Ports per
I/O Controller Module
4
(one SFP port each for channels 0, 1,
4, and 5)
6
(two SFP ports each for channels 1 and
0; one SFP port each for channels 4 and
5)
Maximum Number of
Expansion Units Connected
to a RAID Array
85
Maximum Number of Disks
per Configuration
108 (1 RAID array + 8 expansion
units)
72 (1 RAID array + 5 expansion units)
Maximum Number of
Logical Drives
8 logical drives 8 logical drives
Maximum Total Storage
Capacity
15.75 TB 18.0 TB
Maximum Usable Storage
Capacity
14.0 TB RAID 5
15.1 TB RAID 0
14.0 TB RAID 5
16.0 TB Raid 0
JBOD Array Support One JBOD per server Not supported
TABLE 1-1 Comparison of Sun StorEdge 3510 and 3511 FC Array Features (Continued)
Sun StorEdge 3510 FC Array Sun StorEdge 3511 FC Array
