Chapter 4 Connecting Your Fibre Channel Array 4-11
See the chapter “Checking LEDs” on page 7-1 for more information about your
array’s LEDs.
4.6 Reviewing Channels, Ports, and SFPs
I/O controller modules have ports that accept SFP transceivers. These ports are
labeled FC0 through FC5, to indicate channels 0 through 5. Default configurations do
not include an SFP connector in every SFP port. To add or change SFP connectors,
refer to “Changing Your SFP Configuration” on page 4-18.
The channels and associated ports for the Sun StorEdge 3510 and 3511 FC arrays are
summarized in
TABLE 4-3.
* Only one host port connection per channel is allowed when connecting to a fabric switch.
1
Channel 2 drive ports connect to drive loop A ports on expansion units.
2
Channel 3 drive ports connect to drive loop B ports on expansion units.
TABLE 4-3
Number of Ports in the Sun StorEdge 3510 and 3511 FC Arrays
Item Sun StorEdge 3510 FC Array Sun StorEdge 3511 FC Array
Total number of
ports
68
Channel 0 1 FCO host or drive port;
default: host port
2 FCO dedicated host ports *
Channel 1 1 FC1 host or drive port;
default: host port
2 FC1 dedicated host ports *
Channel 2
1
1 FC2 dedicated drive port 1 FC2 dedicated drive port
Channel 3
2
1 FC3 dedicated drive port 1 FC3 dedicated drive port
Channel 4 1 FC4 host or drive port;
default: host port
1 FC4 host or drive port;
default: host port
Channel 5 1 FC5 host or drive port;
default: host port
1 FC5 host or drive port;
default: host port
