3.2.2 Field-Replaceable Units
Check that you received all field-replaceable units (FRUs) ordered with your Sun
StorEdge 3510 or 3511 FC array. For additional FRUs, consult your sales
representative. For instructions on how to install or replace FRUS, review the
following manuals located on the product web site or on your documentation CD:
■ Sun StorEdge 3000 Family Rack Installation Guide for 2U Arrays
■ Sun StorEdge 3000 Family FRU Installation Guide
All FRUs are hot-swappable except the I/O controller and I/O expansion modules,
which are hot-serviceable. Hot-serviceable means that the module can be replaced
while the array and hosts are powered up but the connected hosts must be inactive.
TABLE 3-1 List of Available Sun StorEdge 3510 FC Array FRUs
FRU Model Number Description
F370-5535-01 BOX, 2U, FC, Chassis + Backplane (RAID/JBOD)
F370-5545-01 BATTERY, FC, 2U
F370-5540-01 CABLE, FC, 1.5 FT, EXPANSION
F370-5537-01 I/O w/SES & RAID CONT FC, 1 GB MEMORY, BATTERY, 2U
F370-5538-01 I/O w/SES, JBOD FC, 2U
F370-5398-01 AC PWR SUPPLY/FAN MOD, 2U
XTA-3310-DC-Kit DC PWR SUPPLY/FAN MOD, 2U
XTA-3510-36GB-15K DRIVE MOD, 36 GB FC, 15KRPM
XTA-3510-73GB-10K DRIVE MOD, 73 GB FC, 10KRPM
XTA-3510-146GB-10K DRIVE MOD, 146 GB FC, 10KRPM
XTA-3510-Ctrl-1G I/O w/SES & RAID CONT FC, 1 GB MEMORY, BATTERY, 2U
XTA-3000-AMBS AIR MANAGEMENT SLED
XTA-3310-RK-19S RACK KIT, 2U, 19" CABINET 22”-28”
XTA-3310-RK-19L RACK KIT, 2U, 19" CABINET 28”-36”
XTA-3310-RK-19C RACK KIT, 2U, 19" CABINET TELCO CENTER MNT
XTA-3310-RK-19F RACK KIT, 2U, 19" CABINET TELCO FRONT MNT
XSFP-LW-2GB SFP, 2G,LW 1310NM, FC, TRANS
XSFP-SW-2GB SFP, 2G, SW 850NM, FC, TRANS
