OPERATION & MAINTENANCE MANUAL SWE18UF
35
2.1 TRANSPORT
2.1.1 General Transport Instructions
Before using a trailer to transport machine, contact local traffic department to confirm relevant
regulations, make sure that machine’s overall length, width, height and weight are within allowed spec.
If there are any dimensions out of spec, obtain special permission from relevant government agencies or
dismantle the machine into smaller unit to transport.
Select proper transportation tools according to machine’s weight, length, width and height.
Survey the traffic condition for transportation in advance, e.g. road condition and width, height of bridges
and tunnels as well as the limits of weight and traffic regulation etc.
Note:
Transportation weight and dimension of the machine may change with different configuration
of the front device and attachments.
2.1.2 Transport Specification
The details of machine dimension are showed in following picture.
A. total height: 2350 mm C. chassis width: 990 mm
B. total length: 3582 mm D. chassis width (track frame extended):1302 mm
E. upper-structure width（cab）: 1302 mm
