OPERATION & MAINTENANCE MANUAL SWE18UF
56
3.13 Operation Procedure of Attachment Control
1. Lower left console to release pilot safety lever ①.
2. Press down the select button of boom swing/ attachment control on the top of left operating joystick, and
hold it, then switch to “attachment” function, changing the right control pedal from boom swing mode to
auxiliary control mode.
3. Control motions of auxiliary pipeline with right control pedal ③.
【Note】：Release the select button of boom swing/auxiliary circuit control on the top of left operating
joystick when attachment control function is not needed to avoid serious accidents caused by accidental
operation.
Details about assembly method of attachment, please contact with the agent designated by Sunward or
attachment manufacturer.
