OPERATION & MAINTENANCE MANUAL SWE18UF
61
4.3.9 Adjustment of Engine Speed
When diesel throttle control lever is push to forefront and engine runs at max. speed; to rearmost end, engine
runs at min. speed; adjust between the range to control the diesel engine speed.
4.3.10 Stopping Engine
1) Lower the bucket to ground.
2) Pull the pilot control lever to LOCK position.
3) Place the accelerator throttle joystick to minimum load, it’s about 5 minutes.
4) Screw key switch to “OFF” position to stop engine, and take out key.
【Important】 Don’t stop engine directly when it is full loaded, it should stop engine after 5 minutes
minimum loaded operation to unload the heat load and avoid possible damage to engine. If engine stop
with load, it should remove load and start engine at once. Before loading, please run 1 minute with half of
the speed.
4.3.11 Using Auxiliary Battery
【Important】Earth the 12V cathode (-), and only use
12V auxiliary battery.
When the battery exhaust, start the engine with auxiliary battery as following instructions.
1) Connect auxiliary battery
Stop engine which is equipped with auxiliary battery.
Connect one end of red wire ① with battery anode (+), and
connect the other end with auxiliary battery anode (+).
Connect one end of black wire ② with cathode of auxiliary
battery, and connect the other end with excavator
framework as ground connection. When connecting with
excavator framework, keep as far as possible away from
the battery connection wire end.
Start engine.
2) Separate auxiliary battery
To Next Page
