OPERATION & MAINTENANCE MANUAL SWE18UF
46
Press down this button to change the system interface to show work hour meter and rotation speed;
Press it again to change the interface to show time and date.
16—Working hour meter
Here indicates machine working time.
17— Fuel level indication
This indicates the fuel level. The pointer is within green range when the fuel level is normal; if it goes
into the red range, it means fuel in tank is lower than 10%.
18— Engine speed indication
This displays current rotation speed of engine.
3.4 ROCKER CONTROL SWITCH
1— Rocker Switch of Dozer Blade/Chassis extension & retraction
It controls dozer blade and chassis by the upper and lower part respectively.
（Press the button with symbol up to control dozer blade, press it down to control chassis）.
3.5 STARTING SWITCH
【NOTE】: Don’t turn the key from “OFF”to“ON” or “ON” to“OFF” in a short time,
1
1
2
2
3
3
4
4
1
