OPERATION & MAINTENANCE MANUAL SWE18UF
69
avoid damaging drive wheels.
8) If you have to park the machine on the slope, use other
method to prevent machine from sliding.
4.5.6 Operation on Swampy Ground
1) Try your best to avoid traveling on swampy ground.
2) Clean crawler frame if the machine works on very soft ground or is stuck.
3) Slew upper-structure 90 and lower bucket to lift one side of crawler off ground, keep the angle between
boom and arm within a range of 90--110, and place the bucket arc on the ground.
4) Turn the lifted crawler to eliminate mud.
4.5.7 Lifting One Side of Crawler by Boom and Arm
Note:
(a) Keep the angle between boom and arm in the range of
90--110, and place the arc part of bucket on the ground.
(b) Slew upper structure 90 and lower bucket to lift one
side of crawler off ground. Don’t dig into the ground with
bucket teeth when the machine is in backhoe condition.
(c) Place chock under the framework to support machine.
4.5.8 Avoid Tilting
Avoid transverse traveling on a slope. When the machine travels
on a slope, the traveling direction should be accordant with the
gradient. When upgrade and downgrade, keep the bucket pointing
to the traveling direction and lifted 20-30cm to the ground. Lower
bucket at once if the machine is skidding or instable.
