OPERATION & MAINTENANCE MANUAL SWE18UF
38
2.1.6 Unloading
Note
Load the machine only on firm, level ground and
keep a safe distance with the road shoulder.
Chock the machine to prevent the machine
movement during loading process.
The ramp for loading must have enough strength
and width with an maximum slope of 15°, be
sure both side of the ramp is at equal level so that
machine could travel safely.
In case of cold weather, fully warm up the
machine.
Unloading procedure
Switch off idle speed function, set travel speed to low
speed position, adjust engine throttle knob to set engine
speed at low speed.
Raise boom to proper height.
Align the center line of machine track with that of ramp
and travel slowly.
When machine is over the rear wheels of the trailer,
operate on the machine slowly so that the machine
could transfer to the ramp smoothly.
When on the ramp, adjust working equipment angle so
that the angle of boom and arm is within 90-110°.
Lower the bucket to the ground until the machine leave
ramp.
2.1.7 Lifting Machine
Note
Never raise the machine with any worker on it.
Make sure the wire rope has sufficient strength
for the weight of the machine. The service
condition must be in accordance with relevant
forced standard.
Swing the working equipment to the sprocket
end, set the undercarriage and upper structure
parallel. Do not swing to the other direction.
Do not lift the machine in any posture other than
the posture given in the right fig.
When lifting, keep the machine horizontal. Never
