OPERATION & MAINTENANCE MANUAL SWE18UF
59
7) Protection device
Check protection plate and mud fender.
8) Safety
Keep all people away from machine and remove barrier.
4.3.2 Checking Diesel Engine
Place the machine on a horizontal ground, check the engine oil
level (stop engine, the engine oil will return to the tank 15
minutes later)
The oil dipstick should be in the range of “MIN” and “MAX”
mark.
The methods of using and maintaining engine, please refer to
“Instruction Manual of Diesel Engine”.
4.3.3 Electrical Device
Check all switches, indicator lights, safety warning devices, battery electrolyte acidity and fuses.
4.3.4 Air Filter
When indicator light comes on, it means that you should maintain or replace filter element.
4.3.5 Oil Level in Hydraulic Oil Tank
Hydraulic oil filling mark：
75061002 0201
Please pay attention to the followings when filling oil to hydraulic
oil tank:
 Place machine on a horizontal ground and retract all
hydraulic cylinders, the oil level is not allowed to exceed
MAX mark (as the max. position in right figure).
 Similarly, when all hydraulic cylinders extend, the oil level
should be above the MIN mark.
 Choose the recommended oil according to the Lubricant
List.
