OPERATION & MAINTENANCE MANUAL SWE18UF
65
can use arm and boom to help the machine pass (FIG.
3-15).
7) The machine must travel in the pose shown in fig 3-17
when traveling up on a slope of 15° or more.
8) The machine should travel at low speed and in a pose
shown in FIG.3-17 when it is traveling down on a slope of 15°
or more.
【Note】：
 When travelling down a slope, if the control lever
returns to the neutral position, the brake will be
applied automatically.
 When travelling up a slope, the arm can dig into
ground to avoid slipping.
 If the machine shut down suddenly while travelling
down a slope, the control lever return to neutral
position, apply the parking brake, lower the dozer
blade onto ground, and then start the machine.
FIG. 4-10
图. 3-17
20～30cm
20～30cm
90
0
～110
0
90
0
～110
0
FIG. 4-11
图. 3-18
