APPENDIX D - PRINTER WORDS
103
SG-System I Operating Manual
D
Hex
#
Printer Words Hex# Printer Words Hex# Printer Words
00 MEDICAL* 56 PANEL PROGRAM
CHANGED
AC SUCCESSFUL DOWNLOAD ACCESS
01 PENDANT TRANSMITTER 57 SELF-TEST FAILURE AD UNSUCCESSFUL ACCESS
02 FAIL TO REPORT IN 58 SYSTEM SHUTDOWN AE SYSTEM SHUTDOWN
03 RESERVED 59 BATTERY TEST FAILURE AF DIALER SHUTDOWN
04 RESERVED 5A GROUND FAULT B0 SUCCESS FULL UPLOAD
05 RESERVED 5B BATTERY MISSING/DEAD B1 RESERVED
06 RESERVED 5C POWER SUPPLY
OVERCURRENT
B2 RESERVED
07 RESERVED 5D ENGINEER RESET B3 RESERVED
08 RESERVED 5E RESERVED B4 RESERVED
09 RESERVED 5F RESERVED B5 ACCESS DENIED
0A FIRE ALARM 60 RESERVED B6 ACCESS REPORT BY USER
0B SMOKE 61 RESTORE ALARM B7 FORCED ACCESS
0C COMBUSTION 62 OPENING ALARM B8 EGRESS DENIED
0D WATER FLOW 63 CLOSING ALARM B9 EGRESS GRANTED
0E HEAT 64 SOUNDER/RELAY BA ACCESS
0F PULL STATION 65 BELL 1 BB ACCESS
10 DUCT 66 BELL 2 BC ACCESS
11 FLAME 67 ALARM RELAY BD ACCESS
12 NEAR FIRE ALARM 68 TROUBLE RELAY BE RESERVED
13 RESERVED 69 REVERSING BF ARMED STAY
14 PANIC ALARM 6A NOTIFICATION
APPLIANCE 3 CHECK
C0 KEYSWITCH ARMED STAY
15 DURESS ALARM 6B NOTIFICATION
APPLIANCE 4 CHECK
C1 RESERVED
16 SILENT ALARM 6C RESERVED C2 RESERVED
17 AUDIBLE ALARM 6D RESERVED C3 RESERVED
18 DURESS 6E SYSTEM PERIPHERAL C4 RESERVED
19 DURESS 6F POLLING LOOP OPEN C5 RESERVED
1A RESERVED 70 POLLING LOOP SHORT C6 GROUP CLOSING
1B RESERVED 71 EXPANSION MODULE
FAILURE
C7 GROUP OPENING
1C RESERVED 72 REPEATER FAILURE C8 EXCEPTION O/C
1D RESERVED 73 LOCAL PRINTER PAPER
OUT
C9 EARLY O/C
1E BURGLARY 74 LOCAL PRINTER FAILURE CA LATE O/C
1F PERIMETER 75 EXPANSION MODULE DC
LOSS
CB FAIL TO O/C
20 INTERIOR 76 EXPANSION MODULE
LOW BATTERY
CC FAIL TO O/C
21 24 HOUR 77 EXPANSION MODULE
RESET
CD AUTO ARM FAIL
22 ENTRY/EXIT 78 RESERVED CE O/C PARTIAL ARMED
23 DAY/NIGHT 79 EXP. MODULE TAMPER CF EXIT ERROR
24 OUTDOOR 7A EXP. MODULE AC LOSS D0 USER PRESENT
25 TAMPER 7B EXP. MODULE SELF-TEST
FAIL
D1 RECENT CLOSE
26 NEAR BURGLARY
ALARM
7C LOSS SUPERVISORY RF D2 SOUNDER/RELAY DISABLED
27 INTRUSION VERIFIER 7D RESERVED D3 BELL 1 DISABLE
28 GENERAL ALARM 7E RESERVED D4 BELL 2 DISABLE
29 POLLING LOOP OPEN 7F RESERVED D5 ALARM RELAY DISABLE
2A POLLING LOOP SHORT 80 RESERVED D6 TROUBLE RELAY DISABLE
2B EXPANSION MODULE
FAILURE
81 RESERVED D7 REVERSING RELAY DISABLE
2C SENSOR TAMPER 82 COMMUNICATION D8 NOTIFICATION APPLIANCE 3 DISABLED
Table 41: Printer Words
