CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
78
SG-System I Operating Manual
5
AA = 51
AB = 38
AC = 60
AD = 00
AE = 00
AF = 00
Option 1B0: CCITT Audio Format Enable Bits
Default (00)
This option is similar to Option 7F. Use this option to enable and disable audio for the selected CCITT formats. A 1 in the formats bit posi-
tion will enable the format for audio. An 0 in the formats bit position will disable audio for the format.
Bit 0 Robofon Format
Bit 1 VONK Format
Bit 2 Stratel Format
Bit 3 CESA FOrmat
Bit 4 Telnot format
Bit 5 Outel format
Bit 6 Not used
Bit 7 Not used
For example, to enable audio to work only for Robofon and Telnot formats, Option 1B0 must be programmed as 11 hexadecimal. This
enables bit 0 and bit 4.
Option 1B1: DMP Area BIN or DEC Option
Default (00)
This option is similar to the DMP receiver.
00 = Area is sent to the automation in BINARY
01 = Area is sent to the automation in DECIMAL
The printer outputs remain unchanged.
Examples: Area is sent to the line card as C0
BINARY setting:
Automation:
P01001 20999 L0480TIMAREA 1
P01001 20999 L0440TIMAREA 2
Printer:
00-01-001-20999--Close USR:04 AREA1 TIMAREA 1
00-01-001-20999--Close USR:04 AREA2 TIMAREA 2
DECIMAL setting:
Automation:
P01001 20999 L0401TIMAREA 1
P01001 20999 L0402TIMAREA 2
Printer:
00-01-001-20999--Close USR:04 AREA1 TIMAREA 1
00-01-001-20999--Close USR:04 AREA2 TIMAREA 2
