Sur-Gard System I - Option 029: Mask Parallel Printer; Option 02 A: Mask Serial Printer; Option 02 F: Automation Mode

CHAPTER FOUR - OPTIONS: SYSTEM
36
SG-System I Operating Manual
4
Option 029: Mask Parallel Printer
Default (OFF)
Use this option to enable the Parallel Printer trouble mask. If enabled, trouble conditions are not reported.
OFF - Condition reported
ON - Condition not reported (masked)
NOTE: Refer to UL864 Programming Requirements on page 10 if changing the default setting.
Option 02A: Mask Serial Printer
Default (OFF)
Use this option to enable the Serial Printer trouble mask. If enabled, trouble conditions are not reported.
OFF - Condition reported
ON - Condition not reported (masked)
NOTE: Refer to UL864 Programming Requirements on page 10 if changing the default setting.
Option 02F: Automation Mode
Default - Fallback (01)
The TCP/IP connection is the primary output of the SG-System I for automation computer alarms. It is expected that sockets may appear and
disappear regularly as processes are terminated and reconstituted. After five seconds of socket loss, a socket loss is declared and automation
output is shifted to the next connection level, which is the serial automation output connection. There are five levels of automation:
Loop (00)
At startup, the SG-System I will send to the TCP/IP until it fails, proceed to the RS232 until it fails, proceed back to the TCP/IP
until it fails, and so on. Please refer to the Automation Mode workflow diagrams below.
NOTE: This value will not generate an automation absent message.
Fallback (01)
If both outputs are present, the system will send to the TCP/IP connection until it fails, proceeding next to the RS232 connection.
It will continue to send to the serial connection without stop, or until the reset fallback command is generated from the console, in
which case it will re-try the TCP/IP connection. Please refer to the Automation Mode workflow diagrams below.
Automatic IP Fallback (04)
This mode is similar to Fallback, save that when the TCP/IP connection is restored the SG-System I will return to the TCP/IP port
to send events. This eliminates the need for the Reset SG Fallback from the SG-System I Console. Please refer to the Automation
Mode workflow diagrams below.
NOTE: The SG System I must be restarted for these changes to take effect.
