CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
61
SG-System I Operating Manual
5
Option 17A: Four- and Five-Digit Account Codes To Activate Two-Way Radio
Default (00)
Use this option to determine which four- and five-digit account codes will be able to activate the 2-way audio feature. Use Option 17A to set
the first two digits of a desired account code.
For example:
To allow all account codes between 1000 and 2FFF to activate the 2-way audio function, program Option 17A as 12.
To allow all account codes between 3000 and 6FFF to activate the 2-way audio function, program Option 17A as 36.
To disable the 2-way audio function, program Option 17A as 00.
NOTE: Either Option 104: Audio Time or Option 111: Hook Flash must be enabled to activate the two-way audio feature of
the line card.
NOTE: Option 17A may be used with any of the formats supported by the receiver.
Option 17B: Three-Digit Account Codes To Activate Two-Way Radio
Default (00)
Use this option to determine which 3-digit account codes will be able to activate the 2-way audio feature. Use Option 17B to set the first
three digits of a desired account code.
For example:
To allow all 3-digits account codes between 200 and 3FF to activate the 2-way audio function, program Option 17B as 23.
To allow all 3-digit account codes between 300 and 6FF to activate the 2-way audio function, program Option 17B as 36.
NOTE: Either Option 104: Audio Time or Option 111: Hook Flash must be enabled to activate the two-way audio feature of
the line card.
NOTE: Option 17B may be used with any 3-digit account code formats supported by the receiver.
Option 17C: Audio Alarm Code Range
Default ()
Use this option to determine the range of alarm codes able to activate the 2-way audio function.
For Example:
The receiver can initiate audio by using Options 17A and 17B, Option 17C, or both.
If all alarm codes beginning with 6, 7, and 8 are to activate 2-way audio, program Option 17C as 68. Option 17C may be used with 10 to 40
Baud formats, DTMF 4/1, 4/2, 4/3 formats, and Contact ID.
You can set Option 17C as 00 to disable this function.
Example: 4/2 format with account code 1234, alarm code 2 on zone 3. (1234-23)
