CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
74
SG-System I Operating Manual
5
Option 1A1: FBI RS-232
Default (01)
You can use this option to enable your computer for FBI Super Fast protocol.
• 00 - Disabled
• 01 - Enabled
When enabled, the computer output will be as shown below:
JRRLLLssssssAAAATZZEss[DC4]
Refer to the table below for an explanation of the computer output:
Option 1A2: Digit Replace
Default (00)
Option 177 works in conjunction with Option 1A2. When Option 1A2 is enabled, and Option 177 is programmed with an ASCII value, the
receiver will replace or insert an account code digit. Option 1A2 is determines how to replace or insert a digit.
To replace a digit, set Option 1A2 to 0x where x is the digit to be replaced.
To insert a digit, set Option 1A2 to 8x where x is the digit in the account code, after which will be the inserted digit.
Option 1A3: D6500 RS232
Default (00)
You can use this option to strip hexadecimal digits from the automation software output. The line card will emulate the Radionics 6500 RS-
232 protocol on pulse formats for Ademco Express and Varitech only.
Table 30: FBI Super Fast Protocol
Output segment Description
J FBI protocol identifier
RR Receiver number
LLL Line number
s Spaces
AAAA Account code
T Zone type
ZZ Zone number, in hexadecimal
E Event code
If E = 0 and T = 0 Listen in
