CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
75
SG-System I Operating Manual
5
Option 1A3 is set to 01
The hexadecimal digit will be stripped for 1-digit reporting codes, including Varitech 4/1.
Example 1: Code 1
Computer output: 104091sssssss022sAsss1
Example 2: Code B
Computer output: 104091sssssss022sOssss
Option 1A3 is set to 02
The hexadecimal digit will be stripped for 2-digit reporting codes, including Varitech 4/2.
Example 1: Code 21
Computer output: 104091sssssss022sAss21
Example 2: Code B1
Computer output: 104091sssssss022sOsss1
Option 1A3 is set to 03
The hexadecimal digit will be stripped for 1- and 2-digit reporting codes, including Varitech.
Option 1A3 is set to 04
The hexadecimal digit will be stripped for BFSK.
Example 1: Code 21
Computer output: 604091sssssss022sAss21
Example 2: Code B1
Computer output: 604091sssssss022sOsss1
NOTE: This option will only work if Option 1A4 is set to 01.
Option 1A3 is set to 05
The hexadecimal digit will be stripped for 1-digit reporting and BFSK.
Option 1A3 is set to 06
The hexadecimal digit will be stripped for 2-digit reporting and BFSK.
Option 1A3 set to 07
The hexadecimal digit will be stripped for 1-digit, 2-digit, and BFSK.
Option 1A3 set to 0F
The hexadecimal digit will be stripped for 1-digit, 2-digit, BFSK, and Ademco Express (4-1, 4-2).
NOTE: Option 170 must be left as an individual event code when enabling Option 1A3.
Option 1A4: BFSK RS-232
Default (00)
You can set this option as 00 to report the BFSK format as Radionics 6500 BFSK mode to the computer; the protocol identifier will be the
numeral 6.
Example 1: Code 21
Computer Output: 604091 022sAsss1
Example 2: Code B1
Computer Output: 604091 022sOsss1
You can set this option as 01 to report the BFSK as a standard 3/1 extended format; the protocol identifier will also be changed from 6 to 1.
