Sur-Gard System I - Option 196: 4;1 Extended; Option 197: 4;2 Extended; Option 198: 3;1 Extended

CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
70
SG-System I Operating Manual
5
RR-LLL-AAA-YZ-Message (3/2)
RR-LLL-AAA-Z-Message (3/1)
RR-LLL-AAAAA-Z-Message (5/1)
Option 196: 4/1 Extended
Default (00)
You can set this option as 01 to enable combining two round pairs of 4/1 extended format into 4/2 output for reporting to the automation and
the printer. For example, with Option 196 enabled, the security control panel can transmit one of the following sets of information:
1234 3
1234 3
3333 1
3333 1
The SG-System I will interpret this information as 1234 31.
The default value of 00 disables Option 196.
Option 197: 4/2 Extended
Default (00)
You can set this option as 01 to combine two round pairs of 4/2 extended format into 4/3 output for reporting to the computer and the printer.
Program one of the following:
Example 1:
1234 05
1234 05
0505 16
0505 16
The SG-System I will interpret this information as 1234 516 .
Example 2:
1234 03
1234 03
3333 01
3333 01
The SG-System I will interpret this information as 1234 301.
Note that a longer online time is required for this format than for a standard 4/2 format. The default value of 00 disables Option 197.
Option 198: 3/1 Extended
Default (01)
You can set this option as 01 to combine two round pairs of 3/1 extended or 3/1 partial extended format into 3/2 output for reporting to the
computer and the printer.
For example, with this option enabled, the security control panel can transmit one of the following sets of information:
