CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
67
SG-System I Operating Manual
5
Option 192: Pulse Mode
Default (00)
00 - Standard Pulse Detection
01 - 50 Baud Pulse Detection
02 - Forced (AAA) Pulse Detection, meaning that only PULSE is detected.
8x - When this bit is enabled it acts as a minimum burst rejection option ,where x can can range from 1 to F (1msec to 15msec).
Option 193: Minimum Audio Tone
Default (00)
Use this option for two-way audio tone detection from specific audio panels. Leave this option as per the default value, unless otherwise
instructed by DSC Technical Support.
Option 194: Account Digit Stripping
Default (00)
There will be circumstances under which output from the SG-System I will not be correctly read by a particular version of automation soft-
ware, most likely an older version. Using Option 194 you can remove those characteristics from the output - e.g. padded zeroes, filler data -
to ensure that this problem is avoided. The various approaches available to format account codes are detailed below.
To Disable Option 194 - Value 00
To disable Option 94, set the value to 00.
To Strip an Account Code of an ‘F’ - Value 01
Standard 4/2 format Output:
1RRLLLssssssAAAAsXssYZ
When Option 194 is set to 01, the leading digit of a four-digit panel account code will be stripped if it is an F.
For Example:
Option 194 is set to 01. The panel account code is F245.
104091ssssssF245sXssYZ
04 four-second interval
05 five-second interval
06 six-second interval
07 seven-second interval
08 eight-second interval
09 nine-second interval
Table 28: Inter-Handshake Duration
Value Length (sec)
