CHAPTER FOUR - OPTIONS: SYSTEM
40
SG-System I Operating Manual
4
Option 03B: Last Message On
Default (Off)
When enabled, this option displays the most recent printer message on the lower line of the unit LCD. It will remain there until a new printer
message replaces it. The automation condition - e.g. mode (Active / Manual) or slot (all / TCP / Serial) - does not have any effect on this fea-
ture.
Option 03C: LCD Backlight Colour
Default (Cyan)
You can use this option to select the LCD backlight colour. Available colours are: OFF / WHITE / GREEN / BLUE / MAGENTA / CYAN /
ORANGE / PURPLE / AQUA / PINK / ROYAL / FADE / CYCLE.
When accessing this option, the available colours will appear on the LCD as you cycle through them, providing a preview of their effect.
This is done without your needing to exit the menu.
Option 03D: Key Backlight Colour
Default (Cyan)
You can use this option to select the LCD backlight colour. Available colours are: OFF / WHITE / GREEN / BLUE / MAGENTA / CYAN /
ORANGE / PURPLE / AQUA / PINK / ROYAL / FADE / CYCLE.
When accessing this option, the available colours will appear on the LCD as you cycle through them, providing a preview of their effect.
This is done without your needing to exit the menu.
NOTE: Please refer to Table 8: LCD Backlight Colour on page 40.
Table 8: LCD Backlight Colour
Colour Description
Off Light grey.
White ~ Royal As per its name.
Fade A static blend of all available colours from white to royal.
Cycle Rotates through all available colours from white to royal at one second intervals.
Yellow Reserved for Trouble mode.
Red Reserved for Manual mode.
