CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
73
SG-System I Operating Manual
5
You can set this option as 01 to leave the Ademco High Speed fully coded, and the received data is passed to the outputs.
automation: 8RRLLLAAAAsCCCCsCCCCsC[DC4]
printer: RR-LLL-AAAA--ccccccccc
Where 8 = protocol number
RR = receiver number
LLL = line number
AAAA = account code
CCCC = channel 1-4
s = space
CCCC = channel 5-8
s = space
C = Channel 9
[DC4] terminator
On the SG-System I this option also controls the Scantronics formats:
2-8-1,5-8-1,6-8-1 (9-digit channels) and 2-16-1,3-16-1,4-16-1,5-16-1,6-16-1 (17-digit channels).
Refer to Option AO (11- and 12-digit DTMF) for configuring conflicting formats.
When this option is programmed as 00, the SG-System I will convert the outputs in the corresponding 2-2,3-2,4-2,5-2 format:
automation: 1RRLLLssssAAAAAAsXssYY[DC4]
printer: RR-LLL-AAAAAA-YY-Alarm
Wehn this option is programmed as 01 the Scantronics formats will not be decoded and the received data is passed to the outputs.
automation:
8RRLLLAAAAAAsCCCCsCCCCsC[DC4] (9-digit channels)
8RRLLLAAAAAAsCCCCsCCCCsCCCCsCCCCsC[DC4] (17-digit channels)
printer:
RR-LLL-AAAAAA--ccccccccc (9-digit channels)
RR-LLL-AAAAAA--ccccccccccccccccc (17-digit channels)
The above examples are shown with 6-digit accounts; for accounts less than this leading digits are not sent. For example 2-8-1 will be output
as:
8RRLLLAAsccccsccccsc[DC4]
RR-LLL-AA--ccccccccc
Option 1A0: 11-/12-Digit DTMF (Acron, Scantronics, or Scancom 433)
Default (00)
You can set this option as 00 to decode an 11- or 12-digit DTMF in ACRON format.
You can set this option as 01 to decode an 11- or 12-digit DTMF in SCANTRONICS format.
You can set this option as 02 to decode an 11- or 12-digit DTMF in Scancom 433 format.
Incoming Format Decoded Format
00 11-digit DTMF Acron 3-8
00 12-digit DTMF Acron 4-8
01 11-digit DTMF Scantronics 2-8-1
01 12-digit DTMF Scantronics 3-8-1
02 12-digit DTMF Scancom 433 4-3-3-FF
