CHAPTER FIVE - OPTIONS: CHANNELS 1 and 2
58
SG-System I Operating Manual
5
Values programmed in Options 30 - 5F, 70 elsewhere other than in this table will default to UAxx for Undecoded Alarm.
Bit3 - Convert BFSK format to SIA
The BFSK outputs will be converted to SIA. The automation output will use the protocol ID of ‘R’.
When this bitwise value is set it has precedence over the BFSK RS232 Option A4. The accounts 3/x to 4/x in Option 76 may be used to
insert a leading ‘0’ to the account code.
E.g. [#123|NFA1]
Bit4 - Convert a comma (‘,’) to a forward slash (‘/’)
When this bitwise value is enabled, any commas will be converted to a forward slash.
E.g. [#1234|NBA1,2,3] becomes [#1234|NBA1/2/3]
Table 21: SIA Conversion
Value Code SIA
41 A BA
42 B BA
43 C CL
46 F FA
48 H HA
4F O OP
4D M MA
50 P PA
52 R BR
54 T TA
5C \ OC
62 b BR
66 f FH
68 h HH
6D m MH
70 p PH
74 t TH
7C l UB
