SUSS MA6 - Pneumatic Plan, Rev: 06-G, Sheet 1 of 8

Appendix
MA6 / MA8 - 3 Appendix - Rev.05 07-06
59
3
151430 PRESSURE REGULATOR 0-1 BAR
162324 POTENTIOMETER WIRE BOUND 10KOHM
149878 PRECISION POTENTIOMETER 100 KOHM
159913 SWITCH - SPLITFIELD
159914 SWITCH - BSA/IR
159912 SWITCH - MAGNIFICATION BSA
149987 SWITCH - ILLUMINATION - ON/OFF
149988 SWITCH- OPENER
149989 SWITCH - SHUTTER
150906 L-CONNECTION
150940 THROTTLE VALVE M5 SW12
150903 CONNECTION COUPLING M5 SW7 LG10
150922 SCREWED PLUG CONNECTION FOR HOSE 4X1
135069 PRESSURE REGULATOR 0-1 BAR
150937 T-SWIVEL CONNECTION
150914 T-SWIVEL CONNECTION M5 FOR HOSE 4X1
150924 OUTLET RESTRICTOR 47.200
150895 T-SWIVEL CONNECTION M5 14X7X11.5
166666 BASE PLATE CPL. MA6/BA6
149992 MUSHROOM BUTTON WITH KEY
149993 SWITCH
108278 MAINS WIREING MA6/BA6
150068 MAIN SWITCH T3-1-102/EA/SVB-SW
158611 PROTECTIVE CIRCUIT BREAKER PROPAK 4A/250VAC 2POLAR
PHB22-A8-SX-22-H-A-4-2
150906 L-CONNECTION
151107 SCREWED PLUG CONNECTION
150922 SCREWED PLUG CONNECTION FOR HOSE 4X1
150914 T-SWIVEL CONNECTION M5 FOR HOSE 4X1
151089 PNEUMATIC ELECTRONIC SWITCH
150899 REDUCING NIPPLE R 1/8" M5 SW 14
150917 PRESSURE REGULATOR R1/8" 0-7BAR
108277 ELECTRONIC RACK MA6/BA6
113824 PC-BOARD MOTOR CONTROL MA6/BA6
146453 FUSE SLOW BLOW 3.15A DIN 41571
114307 PC-BOARD MICROCONTROLLER 8BIT BANKING
150750 SWITCH
166757 ELECTRONIC MODULE INSERT MA6/BA6
114142 PC-BOARD DISTRIBUTOR PLATE BA6
146453 FUSE SLOW BLOW 3.15A DIN 41571
146876 FUSE SLOW BLOW 2.0A DIN 41571
163001 SPARE PART KIT FOR MASKALIGNER MA6 / MA8 B A6 MJB3
146449 FUSE SLOW BLOW 1A DIN 41571
