SUSS MA6 - 3.3 Spare Parts Llist (Extract)

Appendix
MA6 / MA8 - 3 Appendix - Rev.05 07-06
57
3
3.3 Spare Parts Llist (Extract)
167330 SUSS MA6/BA6 MASK- UND BONDALIGNER STANDARD
106969 ALIGNMENT STAGE MA6/BA6
111609 Z-STROKE MA6/BA6
130727 SPINDLE
158792 COMBINATION MOTOR 3557 + ALTERNATOR HEDS 5500 A+CABLE
144845 TOOTHED BELT T 2,5 Z 152 B 6 L 380
111654 WEDGE ERROR COMPENSATION HEAD MA4/6-BSA
124500 GLAS CYLINDER DIA12
152106 O Ring NBR 769-9x1,5
152192 O Ring NBR 769-127x2
152168 O Ring NBR 769-110x2
152254 O Ring NBR 769-95x2
130086 COMPRESSION SPRING
125370 BRAKE SCREW
153042 GROOVED BALL BEARING
172959 TENSION SPRING
150896 L SWIVEL CONNECTION M5 FOR HOSE 5X1
152095 O-RING 015.30X002.40 72 NBR/872
146113 PROXIMITY SWITCH/IND/NPN/7X45
119243 COMPRESSION SPRING
119242 TENSION SPRING 0.5X3X12
150910 L-BANJO L M5 4X1 MOVEABLE BANJO FITTING
150893 DISTRIBUTOR FOR HOSE M5X1
111615 X-Y-Θ-STAGE MA6/BA6
112023 GUIDE LINEAR AXIS ROTATION
149807 PROXIMITY SWITCH/IND/NPN/S/2.0/8X8X20
152438 TENSION SPRING
149807 PROXIMITY SWITCH/IND/NPN/S/2.0/8X8X20
158792 COMBINATION MOTOR 3557+ALTERNATOR HEDS 5500 A +CABLE
112011 STAGE CASING MA6/BA6
144859 MICROMETER SCREW, 20MM, ADJUSTMENT X-Y-TRAVEL
143761 MICROMETER SCREW, 25MM, ADJUSTMENT ROTATION
144169 COUPLING MASTER SELFSEALING RED M5 R1/8"
150909 L-SWIVEL CONNECTION M5 FOR HOSE 4X1
150896 L SWIVEL CONNECTION M5 FOR HOSE 5X1
150922 SCREWED PLUG CONNECTION FOR HOSE 4X1
150893 DISTRIBUTOR FOR HOSE M5X1
150910 L-BANJO L M5 4X1 MOVEABLE BANJO FITTING
150892 CONNECTION M5 SW7 L11.5
150906 L-CONNECTION
