SUSS MA6 - Page 94

1 2 3 4
A
B
C
D
4321
D
C
B
A
.DOC_FILE_NAME_NO_PATH
Sheet of
File :
3 3
Drawn by:
Size : Date : 12-Aug-2005
J.Wanning
A4_l
DrawingNo.: Rev.: AssemblyNo.:
108278
12
103501
Machine: Title:
Base Wiring GroundplateMA/BA6
Rev. Änderung Datum Name
Error : \\Augustus\Programme\Design Explorer 99 SE\System\microtec_logo_1.BMP File Not Supported
Rev.: 13
assy. mains connection
This drawing contains information which is the proprietary of Karl Suss Company.
It is received in confidence an its contends may not be disclosed without the prior
written consent of Karl Suss Company.
Kabelliste für Bgr. Grundverdrahtung zum Stromlaufplan
-W3001
-W3002
-W3003
-W3004
-W3005
-W3006
-W3007
-W3008
-W5001
-W1001
-W1002
Netzleitung 3 x 1,5
Netzleitung 3 x 0,75
LiYY 7 x 0,25
Ruflakabel 10pol.
Sondenkabel 2 x 0.14
LiYY 4 x 0.5
LiYY 2 x 0.5
LiYY 5 x 0.25
LiYY 2 x 0.5
LiYY 4 x 0.25
LiYY 6 x 1.0
146474
149784
148614
146405
146407
146405
146406
150824
146089
147357
keine
Kabel Nr. Kabeltyp EDV-Nr.
+ESB und F-Automat
+ESB
07
08
8.04.99
8.04.99
lge
lge
-ESB / + Heißleiter -R1
09
2.07.99 lge
+ Heißleiter -R2
10
21.07.00 lge
- Rev 10 / + X10A u. F6
11
5.06.01 lge
12
diverse in Plan 01 + 02 26.09.01 jla
